Do you suspect an inaccuracy in our data?
Country Flag

Beechcraft

200 Super King Air

UTILITY


Family:
Beechcraft Super King Air
Type:
Turboprop airplane

Origin:
Country FlagUnited States
Manufacturer:
1972–present

Related:
Beechcraft 1300 Commuter

Updated March 8, 2024
Aircraft picture
200 Super King Air - Ronnie Robertson. CC-BY-SA-2.0

General characteristics (16)

  • Role
    Utility
  • Wing
    Fixed wing
  • Engine count
    2
  • ICAO type designator
    BE20
  • Body
    Narrow
  • Landing gear
    Tricycle retractable
  • Tail
    T-tail
  • Wing position
    Low wing
  • Engine position
    (Front) Wing leading mounted
  • WTC
    L
  • APC
    B
  • Type code
    L2T
  • ADG
    II
  • TDG
    2A
  • SRS
    III
  • LAHSO
    7

Structural data (9)

  • Length
    13.36 m (43.83 ft)
  • Height (overall)
    4.52 m (14.83 ft)
  • Wing area
    28.15 m² (303.01 sq ft)
  • Wingspan
    16.6 m (54.5 ft)
  • Parking area
    292.1 m2 (3,144.4 ft2)
  • Main gear config
    D
  • Cockpit to main gear
    4.6 m (15.0 ft)
  • Main gear width
    5.2 m (17.2 ft)
  • Wheelbase
    4.6 m (15.0 ft)

Performance (1)

  • Service ceiling
    9,450 m (31,000 ft)

Speeds (7)

  • Design maneuvering (VDM)
    182 kt (337 km/h)
  • Flaps extended (VFE)
    155 kt (287 km/h)
  • Gear extended (VGE)
    182 kt (337 km/h)
  • Gear operating (VGO)
    164 kt (304 km/h)
  • Operating (VOP)
    270 kt (500 km/h)
  • Operating Mach
    0.48
  • FAA approach
    107 kt (198 km/h)

Indicative Flight Profile data (23)
Source:SKYbrary logoSKYbrary [1]

  • Takeoff
    V2: 115 kts
    Distance: 570 m
    Weight: 5670 kg
  • Initial climb (to 5000 ft)
    IAS: 145 kts
    ROC: 2000 ft/min
  • Initial climb (to 15,000 ft)
    IAS: 230 kts
    ROC: 1000
  • Initial climb (to 24,000 ft)
    IAS: 230 kts
    ROC: 1000 ft/min
  • Mach climb
    Mach: -
    ROC: -
  • Cruise
    TAS: 260 kts
    Mach: 0,48
    Ceiling: FL350
    Range: 1600 NM
  • Initial descent (to 24,000 ft)
    IAS: -
    ROD: -
  • Descent (to 10,000 ft)
    IAS: 250 kts
    ROD: 1500 ft/min
  • Descent (below 10,000 ft)
    IAS: -
    MCS: 110 kts
    ROD: -
  • Approach
    VAPP (IAS): 100 kts
    Distance: 540 m

Weights (5)

    • MLW
      5,670 kg (12,500 lb)
    • MTOW
      5,670 kg (12,500 lb)
    • MZFW
      4,990 kg (11,000 lb)
    • MTW
      5,711 kg (12,590 lb)
    • FAA weight class
      Small+
